How to Design Metal Stampings
Things We've Learned From Years Making Metal Stampings

12. Edge Conditions of Formed Parts

1. "As Formed" - This is most common and is formed from a controlled size and shape blank.

2. "Die Trimmed" - This is usually simple die trimming and parts have edges similar to flat stampings.

3. "Hemmed Edge" - This is formed for smoothness and stiffness.

Metal Stamping Edge Conditions of Formed Parts

4. "Curled Edge" - This is formed for maximum stiffness and smoothness.

Metal Stamping Edge Conditions of Formed Parts

5. "Lance-Formed" - Edges are likely to have more burr than flat stampings.

Metal Stamping Edge Conditions of Formed Parts
